5KVA Luxpower MPPT Hybrid Inverter +
1x 5.12kWh Dyness Lithium Battery Version 2 +
6x 550W Megatron Tier 1 Solar Panel (HZS-550W)
PLEASE NOTE SOLAR PANELS ARE COURIERED AT OWN RISK
5KVA Luxpower MPPT Hybrid Solar Backup Power Combo Kit
The Perfect MONEY SAVING solution
Lux Power 5KW OFF GRID Inverter (SNA5000WPV)
OUTPUT DATA
Rated power: 5000W/5000VA.
Parallel capacity: YES.
Normal output voltage: 230/240, Split phase 220/110 Vac *
Normal output frequency: 50/60Hz.
Surge power: 10000VA.
Switch time: 10ms.
Waveform: Pure sine wave.
Battery Type: Lithium/Lead-Acid.
Normal Voltage: 51.2V/48V.
Max. Charge Voltage: 59V.
SOLAR DATA
Max. Recommended PV Power: 3200W/3200W.
MPPT Tracker: 2.
Max. PV Open Circuit Voltage: 480Vdc.
MPPT Voltage Range: 100-385Vdc.
Max. Solar Charge Current: 100A.
Max. Solar Input Current: 13A/13A.
Parallel MPPT Charger: YES.
GRID DATA
Normal Voltage: 230Vac.
AC Voltage Range: 110-280Vac.
Max. Charge Current: 60A.
Frequency Range: 50/60Hz(Auto Sensing).
INTERFACE
Display: LCD+LED.
Lithium Battery Communication: CAN/RS485.
RS485/Dry Connector: YES/YES.
Wifi/GPRS: YES/YES.
2 YEARS WARRANTY
SPECIFICATIONS
Dimensions(W/H/D): 330x504x135mm.
Weight 14Kg.
Protection DegreeIP20.
Relative Humidity5%~95% Relative Humidity(Non-condensing).
Operating Temperature0°C~50°C.
Storage Temperature-15°C~60°C.
Applicable for pure off grid/ backup power / self-consumption / on grid situation
Integrated with 2 MPPT solar charge controllers, MPPT ranges 120V~385V
Rated power 5KW, power factor 1
Be able to run with or without battery in On-grid and Off-grid mode
With separated generator input interface, able to control generator remotely
Solar and utility grid can power loads at the same time
With integrated advanced parallel function, up to 9 pcs max paralleling
Support CAN/RS485 for Li-ion battery BMS communication
WIFI/ GPRS remote monitoring included, setting and firmware update, support website, free IOS/Android APP
